    5MHz 75 Ohms CATV Equipment 2.5dB Low Pass Filter High Return Loss

    Ask Lasest Price
    Brand Name : GOOD
    Model Number : 2300
    Certification : NA
    Price : USD0.3
    Payment Terms : L/C, T/T
    Supply Ability : 80000pcs per month
    Delivery Time : 45 days after receiving deposite
    • Product Details
    • Company Profile

    5MHz 75 Ohms CATV Equipment 2.5dB Low Pass Filter High Return Loss

    Coaxial components 75 Ohms high return loss CATV low pass filter


    Features:

    ⊙High Return Loss
    ⊙Low insertion loss.
    ⊙Hugh Sub Band Rejection
    ⊙Sub Band Rejection-50 dB min
    ⊙Quick customization for different bandwidths


    Specification:

    Low pass filter
    ParameterBandwidthSpec.
    Insertion loss5-165MHz2.5dB MAX
    Rejection band loss180-1000MHz50dB MIN
    Flatness5-165MHz+-0.75dB MAX
    Group delay5-165MHz20ns/MHz MAX
    Impedance75 Ohms
    Return loss5-1000MHz16dB Min
    RFI5-1000MHz-120dB

    Product description:

    We manfacture wide range of CATV equipment:

    CATV indoor splitters & taps; have various housing;

    CATV outdoor splitters & taps; have various housing;

    CATV power inserter;

    5-1000MHz attenuator;

    CATV 6KV surge protection isolator;

    High pass filter/low pass filter;

    CATV amplifiers;


    Product overview:


    Application:

    CATV network;


    FAQ

    Coaxial components 75 Ohms high return loss CATV low pass filter​


    Q1. Can I have a sample order for low pass filter


    A: Yes, we welcome sample order for testing and quality checking. Mixed samples are acceptable.


    Q2. What about the lead time?

    A: 3-5 days for Sample preparing ,45 working days for mass production.


    Q3. Do you have MOQ for low pass filter?


    A: MOQ 1000pcs, 1pc for sample checking is available.


    Q4. How do you ship the goods and how long does it take to arrive?

    A: Ship by DHL, UPS, FedEx or TNT. It takes 3-5 days to arrive. Airline and sea shipping also optional.


    Q5. How to proceed an order for ​low pass filter ?

    A: Firstly let us know your detail requirements.

    Secondly We quote according to your requirements.

    Thirdly customer confirms the samples and arrange deposit for formal order. Then we arrange the production.


    Q6. Is it OK to print my logo on sticker of low pass filter?

    A: Yes. Please send us your design.
